The Thrombit™ Clot Retriever Device, featuring S-shaped helical open-side structure, is designed for more efficient clot removal and optimum revascularization in a wide range of vessels.
HELICAL OPEN-SIDE STRUCTURE
enables Thrombite™ retriever to efficiently entwine and clamp the clot
assures clot retention for confident removal and revascularization
OVERLAPPED STENT AT THE HELICAL OPEN-SIDE STRUCTURE
increases contact surface with thrombus and maximizes clot integration
EXCELLENT FLEXIBILITY AND VESSEL WALL APPOSITION
optimizes clot retention during smooth navigation through the tortuous anatomies
3 markers for the sizes with 3.0 and 4.0mm diameter
4 markers for the sizes with 5.0 and 6.0mm diameter
High radial force is designed for clot integration at the initial stage of stent expansion
Low radial force at nominal stent diameter ensures atraumatic retrieval
| Thrombite™ | Product code | Diameter D(mm) | Recommended Vessel Diameter(mm) Min. Max. | Recommende Microcatheter ID (inch) | Working Length A(mm) | Stent Length B(mm) | System Length(mm) | |
| 3MM | CRD-3-15 | 3 | 1.5 | 3.0 | 0.21 | 15 | 27 | 1900 |
| CRD-3-20 | 3 | 1.5 | 3.0 | 0.21 | 20 | 32 | 1900 | |
| CRD-3-25 | 3 | 1.5 | 3.0 | 0.21 | 25 | 37 | 1900 | |
| CRD-3-30 | 3 | 1.5 | 3.0 | 0.21 | 30 | 42 | 1900 | |
| 4MM | CRD-4-15 | 4 | 2.0 | 4.0 | 0.21 | 15 | 27 | 1900 |
| CRD-4-20 | 4 | 2.0 | 4.0 | 0.21 | 20 | 32 | 1900 | |
| CRD-4-25 | 4 | 2.0 | 4.0 | 0.21 | 25 | 37 | 1900 | |
| CRD-4-30 | 4 | 2.0 | 4.0 | 0.21 | 30 | 42 | 1900 | |
| 5MM | CRD-5-15 | 5 | 2.5 | 5.0 | 0.027 | 15 | 27 | 1900 |
| CRD-5-20 | 5 | 2.5 | 5.0 | 0.027 | 20 | 32 | 1900 | |
| CRD-5-25 | 5 | 2.5 | 5.0 | 0.027 | 25 | 37 | 1900 | |
| CRD-5-30 | 5 | 2.5 | 5.0 | 0.027 | 30 | 42 | 1900 | |
| 6MM | CRD-6-15 | 6 | 3.0 | 5.5 | 0.027 | 15 | 27 | 1900 |
| CRD-6-20 | 6 | 3.0 | 5.5 | 0.027 | 20 | 32 | 1900 | |
| CRD-6-25 | 6 | 3.0 | 5.5 | 0.027 | 25 | 37 | 1900 | |
| CRD-6-30 | 6 | 3.0 | 5.5 | 0.027 | 30 | 42 | 1900 | |
The ThromBite™ Clot Retriever Device is intended to restore blood flow by removing thrombus from a large intracranial vessel in patients experiencing ischemic stroke symptom onset.
